Shantui Spare Parts SD22 Steering brake ass'y 23Y-17B-00000
Part Name:Steering brake ass'y
Part Number: 23Y-17B-00000
Machine Model:SD22
| NO. | PART NO. | PART NAME | Q'TY |
| 0 | 23Y-17B-00000 | Steering brake ass'y | 1 |
| 1 | 154-33-11111 | Brake band | 1 |
| 2 | 154-33-13110 | Brake liner | 6 |
| 3 | 04412-00512 | Rivet | 60 |
| 4 | 100-33-13120 | Spring | 2 |
| 5 | 154-33-11530 | Lever | 2 |
| 6 | 154-33-11540 | Lock block | 2 |
| 7 | 154-33-11550 | Adjusting bolt | 2 |
| 8 | 154-33-11610 | Spring | 2 |
| 9 | 154-33-11620 | Plate | 2 |
| 10 | 01010-51016 | Bolt | 4 |
| 11 | 154-33-11510 | Pin | 2 |
| 12 | 154-33-11520 | Washer | 2 |
| 13 | 04050-04040 | Cotter pin | 2 |
| 14 | 154-33-11570 | Lever | 2 |
| 15 | 154-33-11560 | End | 2 |
| 16 | 175-33-24260 | Lock shaft | 4 |
| 17 | 154-33-11650 | Bracket | 2 |
| 18 | 150-33-12171 | Spring | 2 |
| 19 | 154-33-11632 | Support (R.H.) | 1 |
| 19 | 154-33-11642 | Support (L.H.) | 1 |
| 20 | 154-33-11720 | Positioning pin | 4 |
| 21 | 01010-51850 | Bolt | 8 |
| 22 | 01643-31845 | Washer | 8 |
| 23 | 155-33-11130 | Bolt | 2 |
| 24 | 01583-51610 | Nut | 2 |
| 25 | 154-33-22150 | Yoke | 2 |
| 26 | 04205-11645 | Pin | 4 |
| 27 | 01641-21626 | Washer | 4 |
| 28 | 04050-04025 | Cotter pin | 4 |
| 29 | 01508-41610 | Nut | 2 |
| 30 | 154-33-22360 | Yoke | 2 |
